FK-S SERIES

Product parameters

FK-S SERIES

3X1/4-28 UNF+4X3/8-24 UNF sapphire nozzles

FEATURES:

□ Magnetic rotation speed control will reduce wear and gives better jetting impact.
□ Labyrinth Seal can provide a longer lifetime.

TYPES AND SPECIFICATIONS:

TYPES

Max

pressure

Max

flow rate

Diameter
ømm

Length
L=mm

Inlet Connection

FK16S3

（HP Seal）

1600

58 l/min

M24*1.5 Male

3/8 NPT Female (Max 1035bar)

3/8 BSPP Female

9/16" Collar and Gland 13/16-16

FK16S3/P

（Labyrinth Seal）

1600

75 l/min

M24*1.5 Male

3/8 NPT Female (Max 1035bar)

3/8 BSPP Female

9/16" Collar and Gland 13/16-16

FK30S3

（HP Seal）

3000

42 l/min

3/8" Collar and Gland 3/4-16

1-1/8-12 UNF

We specialise in the development and production of high pressure water jetting tools for waterjet technology applications.
